MUMA Solar Cooker- Solar Spaghetti.jpg

The MUMA Solar Cooker, designed by Matteo Muccioli, is composed of four Fresnel lenses and four plane mirrors. It is designed to be transportable and easily reproducible. The idea is to use a system of orientation and positioning that is integrated into the same structure as the cooker, in that way, once focused, it is easy to turn as a unit to follow the sun.

  • N° Fresnel lenses = 4
  • Dimension of lenses = 280mmX210mm
  • Focal length = 280mm
  • Absorbing surface = 0.2352 mq
  • Maximum power to the lenses = 235.20 W

Design drawings[edit | edit source]

2 MUMA SOLAR COOKER ASSEMBLY.jpg
1 MUMA SOLAR COOKER LOGICAL SCHEME.jpg
3 MUMA SOLAR COOKER STRUCTURE 1.jpg
4 MUMA SOLAR COOKER STRUCTURE 2.jpg
5 MUMA SOLAR COOKER STRUCTURAL PARTS 1.jpg
6 MUMA SOLAR COOKER STRUCTURAL PARTS 2.jpg
7 MUMA SOLAR COOKER PLEXIGLAS LENS SUPPORT.jpg
8 MUMA SOLAR COOKER FRESNEL LENS.jpg
9 MUMA SOLAR COOKER FRESNEL LENS ASSEMBLY.jpg

Audio and video[edit | edit source]

  • January 2017:
  • May 2016:
MUMA_Solar_Cooker_(transportable_version)-0

MUMA Solar Cooker (transportable version)-0

This is the prototype of the device

MUMA_Solar_Cooker_Assembly_test

MUMA Solar Cooker Assembly test

This is the assembly test

MUMA_Solar_Cooker_2_Assembly_Test

MUMA Solar Cooker 2 Assembly Test

This is the assembly test 2

MUMA_Solar_Cooker_2_Solar_Spaghetti!!!_-)

MUMA Solar Cooker 2 Solar Spaghetti!!! -)

Cooking spaghetti with the first prototype
